Administrating the Camera
Setting the Sensor input/Camera tampering detection/Motion detection — Action input Menu
53
• An alarm sounds when an object passes through area
A and enters area B.
• An alarm sounds when an object passes through areas
A and B, and enters area C.
• An alarm sounds when an object enters area A, and
passes through area B.
Intrusion
When a moving object enters the designated area, an
alarm sounds.
Passing
A passage line is determined, and when a moving object
passes the setting line, an alarm sounds.
Left object
When a moving object has been left in the designated
area, an alarm sounds.
Removed object
When a moving object has been removed from the
designated area, an alarm sounds.
Notes
• Before actual use, perform an operation test and
confirm that the motion detection function works
correctly.
• When the privacy masking is used, the motion
detection function is not available for the masked area
if Effect is set to Opaque.
Setting items for motion detection
Use the settings tab to set the conditions for the motion
detection function while observing camera images.
Target Image
Select All PTZ position or Preset position.
All PTZ position
This is a common setting for both VMD and VMF
settings regardless of the camera PTZ position.
Preset position
You can set the VMD and VMF settings for each preset
position.
Selected preset
Displays the registered preset positions. Click a preset
position to position the camera, then make the VMD and
VMF settings for that position.
VMD settings
Detection area
Specify the effective scope of motion detection.
Note
The frames shown on the monitor screen are not
displayed on the image files sent or recorded with
motion detection.
Configuring the detection area
The following procedure is used to configure the motion
detection area:
1
Use the following buttons to specify the active
area(s) and inactive area(s).
Add detection area
Clicking this button will add an active area window
in the center of the screen.
When you place the cursor on the area, the cursor
changes to a crossed arrow, which you can drag to
move the area.
Monitor screen
Setting item list
Setting area
