70
Disconnecting/reconnecting cables on the main unit
Correct operation of the main unit when connecting and disconnecting cables, excluding the
HDMI input connector, during operation is not guaranteed.
If you inadvertently disconnect a cable, reconnect the cable and then reboot the main unit.
Before connecting or disconnecting cables, make sure that the power supply is first turned off.
Main display, second display, touch panel
Two displays can be connected. The second display can display a different extended image
than the first display.
For example, different presentations can be shown on the two displays to support large-scale
lectures or meetings.
Also, a second HDMI display can be connected when a DisplayPort-to-HDMI adapter is
connected to the DISPLAY PORT connector.
Notes
Daisy chain connections using the DisplayPort Multi Stream Transport (MST) function are
not supported.
The cursor may not be displayed correctly if a touch panel and mouse are used together.
Except for maintenance, do not use a touch panel and mouse at the same time.
VGA connectors cannot be used.
Assigning the main display and second display
1. Connect two displays to the main unit.
2. Turn on the devices.
3. Open the [Display] page of the [Setting] screen.
4. Select [Extend these displays] or [Clone these displays] in [Multiple Displays].
5. Select the primary display in [Display], and set the following items.
[Resolution]
Select the resolution of the selected display.
[Location]
Select the [Left] / [Right] location of the selected display.
[Make this my main display]
Place a check mark here to set the selected display as the main display.
6. Select the secondary display in [Display], and set the following items in the same way as
for the primary display.
[Location] is automatically set to the opposite value of the primary display.
