52
Large-scale interactive lecture
The following describes how to calculate the required network bandwidth for a large-scale
configuration comprising 6 mirroring user devices and 100 user devices using the Personal
Note Taker function.
Determine the maximum number of simultaneously connected user devices used for mirroring
and the Personal Note Taker function beforehand as described in “Maximum number of
simultaneous mirroring user devices” (page 31) and “Maximum number of simultaneous user
devices for Personal Note Taker function” (page 31) in the “Large-Scale Interactive Lecture”
section.
Pod server
Layer 2 switch
Wireless LAN access point
Streaming output: 6 Mbps
Skype for Business integration:
Ex: 4 Mbps (Up), 4 Mbps (Down)
User devices using Personal Note Taker
Personal Note Taker:
6.4 Mbps (max.) × 100
User devices for mirroring
Mirroring to
main unit:
6 Mbps × 2
+ 1 Mbps × 4
= 16 Mbps
Main Display
User device
(100 devices)
Second Display
(Eqn. A)
User device
(4 devices)
Legend
Dotted arrow: Transfer using wired LAN or wireless LAN
Solid arrow: Transfer using wired LAN
User device
(2 devices)
