Specifications
Specifications
General
Power requirements 100 to 240 V AC, 50/60 Hz
Current consumption 0.35 A
Peak inrush current
(1) Power ON, current probe method:
40 A (100 V), 95 A (240V)
(2) Hot switching inrush current, measured in
accordance with European standard EN55103-1:
25 A (230 V)
Operating temperature
5°C to 40°C (41°F to 104°F)
Maximum cable length
200 m (656 feet)
Dimensions (w/h/d) MSU-900
482 × 222 × 67 mm
(19 × 8
3
/
4
× 2
3
/
4
inches)
MSU-950
204 × 354 × 67 mm
(8
1
/
8
× 14 × 2
3
/
4
inches)
including projecting parts and controls
Mass MSU-900
Approx. 4.5 kg (9 lb 15 oz)
MSU-950
Approx. 3.7 kg (7 lb 18 oz)
Inputs/outputs
REMOTE
CCU/CNU 8-pin multiconnector (1)
AUX 8-pin multiconnector (1)
I/O PORT 50-pin (1)
Ethernet 6-pin (1)
AC IN 3-pin (1)
Supplied accessories
Operation Manual (1)
Operation Manual (CD-ROM) (1)
Optional accessories
AC power cord
• For customers in the USA and Canada
Power cord (125 V, 10 A, 2.4 m (8 feet))
(Part No. 1-551-812-1X)
Plug retainer (Part No. 2-990-242-0X)
• For customers in the European countries
Power cord (250 V, 10 A, 2.4 m (8 feet))
(Part No. 1-782-929-1X)
Plug retainer (Part No. 2-990-242-0X)
Design and specifications are subject to change without
notice.
Note
Always verify that the unit is operating properly before
use. SONY WILL NOT BE LIABLE FOR DAMAGES
OF ANY KIND INCLUDING, BUT NOT LIMITED
TO, COMPENSATION OR REIMBURSEMENT ON
ACCOUNT OF THE LOSS OF PRESENT OR
PROSPECTIVE PROFITS DUE TO FAILURE OF
THIS UNIT, EITHER DURING THE WARRANTY
PERIOD OR AFTER EXPIRATION OF THE
WARRANTY, OR FOR ANY OTHER REASON
WHATSOEVER.
