Je bekijkt pagina 34 van 43
34
Preset menu
The Preset menu is used to set the User1 to 20
preset setting.
Troubleshooting
This section may help you isolate the cause of a
problem and as a result, eliminate the need to
contact technical support.
“Unknown” or “Out Of Range” is displayed.
Input the supported signal (page 38).
The monitor cannot be operated even when
you press the buttons.
The monitor settings cannot be changed.
The monitor cannot be remotely operated.
The key protection function is enabled. Set
the
Control Lock setting to “Off” (page 31).
Menu operations and/or input switching
cannot be performed while monitoring the
signal with AUX IN. Stop monitoring the
sig
nal.
The black bars appear at the upper and
lower positions of the display When the
sig
nal aspect ratio is different from that of the
panel, the black bars appear. This is not a
failure of the unit.
While the logo is displayed, the operation
buttons do not operate when pushed.
While the logo is displayed, the operation
bu
ttons do not operate. After the logo
disappears, the operation buttons can be
operated. The logo display time can be set in
the menu (page 32).
The display is dark. When the unit is used
in a high temperature environment, the
brightness of the display backlight is reduced
to lower the temperature inside the unit. When
this function is activated, the power indicator
flashes in green.
PORT A HD
Clipping Size/
PORT B HD
Clipping Size
Select the clipping size of the HD
s
ignal from “Normal,” “4:3,” “5:4,” or “V
Full” when displaying 2 or 3 screen
displays.
Custom Button Assigns the function to the CUSTOM 1
o
r CUSTOM 2 button on the front
panel, and can set the following
functions to on or off.
No Setting
Scan Size
4K Zoom
Flip Pattern
POP Sub Screen Position
Gamma
Mono
Contrast
Brightness
Chroma
Phase
Clone Out Format
AUX IN
Port C Display
Menu Setting
Load User Setting Loads the settings that are stored
Us
er1 to 20.
Save User Setting Stores the current settings to User1 to
20
.
User Name Registers the user names to User1 to
20
.
Load Default Loads the setting data that is set for
the def
ault preset settings.
Menu Setting
