Specifications
92
HD/SD-SDI closed caption adaptor
BKM-244CC
3G/HD/SD-SDI input adaptor
BKM-250TG
(Install a BKM-250TG that has a
serial number 7400001 or later,
when displaying 3D images using
HD-SDI signal inputs.)
3D glasses (glasses-type)
BKM-30G
3D glasses (clip-on-type)
BKM-31G
3D glasses specifications (supplied)
Glasses-type
Dimensions (W/H):
Approx. 146 × 38 mm (5
3
/
4
×
1
1
/
2
inches)
Mass: Approx. 18 g (0.63 oz)
UV light reduction:
99% (280 nm - 380 nm)
Design and specifications are subject to change without
notice.
Pin assignment
PARALLEL REMOTE connector
Modular connector
(8-pin)
You can allocate functions using the REMOTE menu
(see page 88).
Wiring required to use the Remote Control
Connect the function you want to use with a Remote
Control to the Ground (Pin 5).
SERIAL REMOTE (RS-232C) connector
D-sub 9-pin, female
Available signal formats
The unit is applicable to the following signal formats.
Note
Always verify that the unit is operating properly before
use. SONY WILL NOT BE LIABLE FOR
DAMAGES OF ANY KIND INCLUDING, BUT
NOT LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF THE LOSS
OF PRESENT OR PROSPECTIVE PROFITS DUE
TO FAILURE OF THIS UNIT, EITHER DURING
THE WARRANTY PERIOD OR AFTER
EXPIRATION OF THE WARRANTY, OR FOR ANY
OTHER REASON WHATSOEVER.
Pin number Functions
1 Designating composite input signal
2 Designating component input signal
3 Setting tally lamp green ON/OFF
4 Setting tally lamp red ON/OFF
5 GND
6 Selecting external sync
7 Selecting over scan
8 Selecting normal scan
1
8
Pin number Signal
1 NC
2 RX
3 TX
4 NC
5 GND
6 NC
7 RTS
8 CTS
9NC
System
Compo
site Y/C
BKM-
227W
RGB
Component
BKM-229X
BKM-
220D
BKM-
243HS/
244CC
BKM-
250TG
2D
BKM-
250TG
3D
575/50I
(PAL)
aaaaa
–
480/60I
(NTSC)
*
1
aaaaa
–
576/50P –
a
––––
480/60P –
a
––––
1080/
24PsF
*
1
– a
*
2
–
aaa
1080/25PsF
– a
*
2
–
aaa
1080/24P
*
1
– a
*
2
–
aaa
1080/25P – a
*
2
–
aaa
1080/30P
*
1
– a
*
2
–
aaa
1080/50I –
a
–
aaa
1080/60I
*
1
–
a
–
aaa
720/50P – a
*
2
–
aaa
720/60P
*
1
–
a
–
aaa
1080/50P – – – –
a
–
1080/60P – – – –
a
–
15
69
