Adjustment Using the Menus
77
Recommended: Konica Minolta Color Analyzer CA-
210
USER CONTROL menu
The USER CONTROL menu is used for adjusting the
picture.
Items that cannot be adjusted depending on the input
signal are displayed in black.
For details of input signals and adjustable/setting items,
see page 64.
For the video input
Submenu Setting
COLOR TEMP Selects the color temperature from
among D65, D93 and USER
settings.
MANUAL
ADJUSTMENT
If you set the COLOR TEMP to
USER setting, the item displayed is
changed from black to white, which
means you can adjust the color
temperature.
The set values are memorized.
• ADJUST GAIN: Adjusts the
color balance (GAIN).
• ADJUST BIAS: Adjusts the
color balance (BIAS).
• COPY FROM: If you select D65
or D93, the white balance
data for the selected color
temperature will be copied
in the USER setting.
3D OFFSET Selects the desired mode pertaining
to the 3D offset adjustment.
• AUTO: The setting value of 3D
offset adjustment is not
applied to 2D display mode.
The setting value of 3D
offset adjustment is applied
to 3D display mode.
• OFF: The setting value of 3D
offset adjustment is not
applied to either 2D or 3D
display mode.
• ON: The setting value of 3D
offset adjustment is applied
to both 2D and 3D display
modes.
3D OFFSET ADJ. Available when 3D is selected from
2D/3D SELECT. Defines white
balance for 3D viewing in order to
provide colors as accurate as those
when 3D glasses are not used.
You can select from among R
GAIN, G GAIN, B GAIN, R BIAS,
G BIAS and B BIAS.
COLOR SPACE Selects the color space from among
EBU, SMPTE-C, ITU-709 and
OFF. OFF sets the color space to
the original color reproduction of
the LCD panel.
COLOR TEMP: xxxxxx
MANUAL ADJUSTMENT
ADJUST GAIN:
ADJUST BIAS:
COPY FROM: xxx
3D OFFSET: xx
3D OFFSET ADJ.: xx
COLOR SPACE: x
COLOR TEMP/SPACE
Submenu Setting
AUTO CHROMA/
PHASE
Adjusts color intensity (CHROMA)
and tones (PHASE).
• AUTO ADJ VALUE: Selects
ON or OFF of the auto
adjustment. When you set
to OFF, this parameter is
reset to the factory setting.
When you set to ON, the
automatically adjusted value
is enabled.
• START: The auto adjustment
starts when you display the
color bar signals (Full/
SMPTE/EIA) on the screen
and press the ENTER
button. After adjusting the
color intensity, press the
MENU button to clear the
adjustment screen. After the
adjustment is done correctly,
the AUTO ADJ VALUE is
automatically set to ON.
AUTO CHROMA/PHASE
AUTO ADJ VALUE: xx
START:
USER CONTROL 1/3
SUB CONTROL
CONTRAST: x
BRIGHTNESS: x
CHROMA: x
PHASE: x
APERTURE: x
BACKLIGHT: x
USER CONTROL 2/3
PICTURE CONTROL
ACC: xx
CTI: x
V SHARPNESS: x
INPUT SETTING
SHIFT H: xxx
SHIFT V: xx
USER CONTROL 3/3
