Adjustment Using the Menus
76
GRID
DISPARITY RULER
GRID/RULER INTENSITY
AUTO L/R SW
3G-B DEFAULT CH
DIFFERENCE
VIRTUAL SUB. MAR.
*3 Displayed only when selecting input signals from BKM-
250TG or DVI input signals.
REMOTE
PARALLEL REMOTE
SERIAL REMOTE
KEY INHIBIT
KEY INHIBIT
Adjusting and Changing the
Settings
STATUS menu
The STATUS menu is used to display the current status
of the unit. The following items are displayed:
For the video input
• Signal format
• Color temperature
• Component level
•NTSC setup
• Scan mode
• I/P mode
•PAYLOAD ID
• Model name and serial number
• OPTION A and serial number
• OPTION B and serial number
About Payload ID
Displays the channel assign information of payload ID
superimposed on input signals from the IN (INPUT)-1
and IN (INPUT)-2 connector on BKM-250TG. Going
out of the STATUS menu renews channel assign
information.
• -: Payload ID is not superimposed on signals.
• x: Channel assign information is detected as Link-2 or
Link-3.
• LEFT: Channel assign information is detected as
Link-0.
• RIGHT: Channel assign information is detected as
Link-1.
Payload ID is only available when DUAL is selected in
3D SIGNAL FORMAT under 3D SETTING.
For the DVI/HD15 input
• Signal format
•fH
•fV
• Color temperature
•Power saving
• Model name and serial number
• OPTION A and serial number
• OPTION B and serial number
COLOR TEMP/SPACE menu
The COLOR TEMP/SPACE menu is used for adjusting
the picture white balance or color space.
You need to use the measurement instrument to adjust
the white balance.
FORMAT xxxxxxxxx
xxxxxxxx
COLOR TEMP xxx
COMPONENT LEVEL xxxxx
NTSC SETUP xxxxxxxxx
SCAN MODE xxxxxxxx
I/P MODE xxxxxxx
PAYLOAD ID IN-1:xx IN-2: xx
STATUS 1/2
LMD-2451TD xxxxxxx
OPTION A BKM-220D
xxxxxxx
OPTION B NOT INSTALLED
STATUS 2/2
FORMAT xxx
xxxxxxx
fH xxxxxxx
fV xxxxx
COLOR TEMP xxxx
POWER SAVING xx
STATUS 1/2
LMD-2451TD xxxxxxx
OPTION A BKM-220D
xxxxxxx
OPTION B NOT INSTALLED
STATUS 2/2
