Location and Function of Parts and Controls
67
a a/? (power) switch (LMD-4251TD)
Power switch (LMD-2451TD)
The power is turned on or off.
The monitor is turned on by pressing side ?.
b AC IN socket
Connect the supplied AC power cord.
c 24V connector (LMD-2451TD only)
Plug the DC 24V power supply to this connector to
provide power to the monitor.
Note
Be sure to connect to a power supply of the specified
voltage value.
d AUDIO L/R IN connectors (phono jack)
Connect to the audio outputs of a VCR or to an audio
mixer.
e COMPOSITE IN connector (BNC)
Input connector for composite signals.
f Y/C IN connector (4-pin mini-DIN)
Input connector for Y/C signals.
g G/Y IN connector (BNC)
Input connector for G of RGB signals and component Y
(luminance) signals.
h B/P
B IN connector (BNC)
Input connector for B of RGB signals and P
B (blue color
difference) of component signals.
i R/P
R IN connector (BNC)
Input connector for R of RGB signals and P
R (red color
difference) of component signals.
j EXT SYNC IN/OUT (external sync) connectors
(BNC)
To use the external sync signal, press the function button
that EXT SYNC is assigned (F1 button at the factory
setting).
IN connector
When this unit operates on an external sync signal,
connect the reference signal from a sync generator
to this connector.
Note
When inputting a video signal with the jitters, etc.
the picture may be disturbed. We recommend using
the TBC (time base corrector).
OUT connector
Loop-through output of the IN connector. Connect
to the external sync input of video equipment to be
synchronized with this unit.
When the cable is connected to this connector, the
75-ohm termination of the input is automatically
released, and the signal input to the IN connector is
output from this connector.
k AUDIO L/R OUT connectors (phono jack)
Outputs the audio signal which is selected by the input
select button on the front panel.
When BKM-220D/243HS/244CC/250TG is not
installed, output the audio signal which is selected in
INPUT SELECT of the USER CONFIG menu (see
page 85).
When BKM-220D/243HS/244CC/250TG is installed,
output the audio signal of the channel which is selected
in OPTION AUDIO SETTING of the USER CONFIG
menu (see page 85).
The audio signal from this connector is monitored on the
front speakers (see page 62).
l Loop-through output connectors
Outputs the signals input to the input connectors (5 to
9). Connect to the analog input (composite, Y/C,
analog component or analog RGB) of equipment,
according to the input signal.
m Optional input port
An optional input adaptor can be installed according to
your system configuration (see page 70).
LMD-4251TD has port A on the upper side and port B
on the lower. LMD-2451TD has port A on the left side
and port B on the right.
Press the A-1, A-2, B-1 or B-2 button to select the
signal.
n PARALLEL REMOTE connector (modular
connector, 8-pin)
Forms a parallel switch and controls the monitor
externally.
For details on the pin assignment and factory setting
function assigned to each pin, see page 92.
CAUTION
For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this
port. Follow the instructions for this port.
ATTENTION
Par mesure de sécurité, ne raccordez pas le connecteur
pour le câblage de périphériques pouvant avoir une
tension excessive à ce port. Suivez les instructions pour
ce port.
VORSICHT
Aus Sicherheitsgründen nicht mit einem
Peripheriegerät-Anschluss verbinden, der zu starke
Spannung für diese Buchse haben könnte. Folgen Sie
den Anweisungen für diese Buchse.
