60
Specifications
Input/Output connectors
CAMERA Optical fiber connector (1)
1.485 Gbps/1.4835 Gbps SDI × 2, 240 V
AC power supply
INCOM/TALLY/PGM
D-sub 25-pin (1)
• INCOM (PD / ENG), 4W/RTS/CC,
0 dB
• PGM, 2 systems, 0 / –20 dB
• TALLY (R, G)
RCP/CNU 8-pin multi-connector (1)
TRUNK A 12-pin (1)
TRUNK LINE D-sub 9-pin, female (1)
RS-232C/RS-422, for CHU transmission
or system expansion
I/O PORT D-sub 15-pin, female (1) (JAE-made DA-
C1-J10 recommended)
LAN 8-pin (1)
Input connectors
AC IN (1), 100, 110 to 120, 220 to 240 V AC
switchable
HD SERIAL RET INPUT
BNC-type (4), SMPTE-292M,
Bit rate: 1.485 Gbps/1.4835 Gbps
SD SERIAL RET INPUT
BNC-type (4), SMPTE-259M
Bit rate: 270 Mbps
REFERENCE INPUT
BNC-type (2), loop-through output
HD: SMPTE-274M, tri-level sync,
0.6 Vp-p, 75 ohms
SD: Black burst
(NTSC: 0.286 Vp-p, 75 ohms)
(PAL: 0.3 Vp-p, 75 ohms)
or NTSC 10F-BB
PROMPTER INPUT
BNC-type (4), loop-through output,
analog signal, 1.0 Vp-p, 75 ohms
MIC REMOTE D-sub 15-pin (1) (JAE-made DA-C1-J10
recommended)
Output connectors
MIC OUT XLR 3-pin, male (2), 0 dBs/–20 dBs
AES/EBU BNC-type (1), AES/EBU format
CHARACTER OUT
BNC-type (1), VBS, 1 Vp-p, 75 ohms,
character on/off switchable
WF REMOTE D-sub 15-pin, female (1) (JAE-made DA-
C1-J10 recommended)
SDI OUT BNC-type (4)
HD-SDI: SMPTE 292M, 0.8 Vp-p,
75 ohms, 1.485 Gbps/1.4835 Gbps
SD-SDI: SMPTE 259M, 0.8 Vp-p,
75 ohms, 270 Mbps
HD-SDI/SD-SDI selectable
SDI OUT (MON)
BNC-type (4)
HD-SDI: SMPTE 292M, 0.8 Vp-p,
75 ohms, 1.485 Gbps/1.4835 Gbps
SD-SDI: SMPTE 259M, 0.8 Vp-p,
75 ohms, 270 Mbps
HD-SDI/SD-SDI, and character ON/OFF
selectable
SYNC OUT BNC-type (1)
HD: BTA S001A, tri-level sync,
0.6 Vp-p, 75 ohms
SD: composite sync, 0.3 Vp-p, 75 ohms
HD SYNC/SD SYNC selectable
WF MODE 4-pin (2)
Supplied accessories
Number plates (1 set)
Fuses (1 set)
Operation manual (1)
Optional accessories
AC power cord:
USA and Canada: 1-551-812-XX
Other countries: 1-782-929-XX
Power cord plug holder:
USA and Canada: 2-990-242-01
Other countries: 3-613-640-01
HKCU1001 SD Encoder Unit
HKCU1003 Multi Interface Unit
HKCU1005 SDI Output Expansion Unit
CCA-5-3 Connection Cable (3 meter/10 feet)
CCA-5-10 Connection Cable (10 meter/33 feet)
Expansion Board
Maintenance manual
For the customers in the U.S.A., Canada, Europe,
Australia, and New Zealand
Connectors for optical/electric composite cables:
•LEMO
® PUW.3K.93C.TLCC96 (to the “CAMERA”
connector on CCU)
•LEMO
® FUW.3K.93C.TLMC96 (to the “CCU”
connector on CAMERA)
Caution on the optical/electric composite cable:
For connection between the camera control unit and a
camera, be sure to use an optical/electric signal composite
cable with the connectors specified in this manual in order
to comply with the limit for EMC regulations.
Pour les utilisateurs aux Etats-Unis, au Canada, en
Europe, à l’Australie, et à la Nouvelle-Zélande
Connecteurs pour les câbles optiques/électriques
composites:
•LEMO
® PUW.3K.93C.TLCC96 (au connecteur
«CAMERA» de l’unité de commande de caméra)
•LEMO
® FUW.3K.93C.TLMC96 (au connecteur
«CCU» de la caméra)
