Locations and Functions of Parts
3 VBS 1 to 4 (VBS return video 1/2/3/4) connectors
(BNC-type)
Four different VBS return video input signals may be
received independently.
The selection of RET 1, 2, 3, or 4 is made by the return
switch of the video camera.
The type of input signal on RET 1, 2, 3, and 4 may be set
individually using the setup menu, or using the MSU-900
series Master Setup Unit.
An aspect ratio may also be selected for SD signals.
For details on the setup menu, contact a Sony service or
sales representative.
Refer also to the Master Setup Unit manual.
c (LAN) connector
(RJ-45 8-pin)
For LAN connection. Connect a LAN HUB (10BASE-T/
100BASE-TX), using a LAN cable (shielded type of
category 5 or more).
For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this
port. Follow the instructions for this port.
Par mesure de sécurité, ne raccordez pas le connecteur
pour le câblage de périphériques pouvant avoir une tension
excessive à ce port. Suivez les instructions pour ce port.
Aus Sicherheitsgründen nicht mit einem Peripheriegerät-
Anschluss verbinden, der zu starke Spannung für diese
Buchse haben könnte. Folgen Sie den Anweisungen für
diese Buchse.
d INPUT area
1 PROMPTER 1, 2 (tele-prompter input) connectors
(BNC-type)
Input a teleprompter signal to either of the two connectors.
The input signal is output from the other connector as is
(loop-through output). If loop-through output is not used,
terminate the unused connector at 75 ohms. If the signal
used is a 1.0 Vp-p, 75-ohm signal, it may be output from
the PROMPTER OUT connector of the video camera with
a frequency bandwidth of 5 MHz, regardless of signal
format.
2 REFERENCE connectors (BNC-type)
Input an HD tri-level reference sync signal or SD reference
sync signal (black burst signal) to either of the two
connectors.
The input signal is output from the other connector as is
(loop-through output). If loop-through output is not used,
terminate the unused connector at 75 ohms.
The type of reference signal is selected using the setup
menu, or using the MSU-900 series Master Setup Unit.
For details on the setup menu, contact a Sony service or
sales representative.
To use the VBS signal of the HKCU1001 SD Encoder Unit
or the HKCU1003 Multi Interface Unit (when SC phase
lock is required), use an SD reference sync signal (black
burst signal).
e SPARE connector (BNC-type)
Reserved for future use.
f OUTPUT area
1 SYNC (sync signal output) connector (BNC-type)
Used for output of SD composite sync signal or an HD tri-
level sync signal from the internal sync signal generator.
(Factory setting: SD composite sync)
For details on the signal selection, contact a Sony service
or sales representative.
2 CHARACTER (character output) connector
(BNC-type)
Outputs the self-diagnostic results or the setup menu as an
SD monochrome analog video signal.
3 AES/EBU connector (BNC-type)
Outputs an AES/EBU format digital audio signal input to
a video camera.
g CAMERA connector (optical fiber connector)
Used to connect a video camera, using an optical fiber
cable.
All video camera signals, including power supply, control,
video, and audio, are sent and received over one optical
fiber cable.
Dust on the connection surface of the optical fiber cable
may result in transmission errors.
When not connected, always cover the end of the
connector with the supplied cap.
CAUTION
ATTENTION
VORSICHT
Note
Note
