4
Overview
Overview
The HKC-HB10/HB15 and HKCU-HB10/HB15 3G Fiber
Transmission Units are function enhancement units for
Sony HD color cameras or HD camera control units.
The applicable cameras and camera control units are
shown in the table below.
1) Only HDCU1000 units of serial number 14001 or higher (UC), 44001 or
higher (CE), or 410001 or higher (CE) are applicable.
Installing these units provides conventional HD color
camera and HD camera control units for HD-SDI optical
transmission with “High Bit Rate” optical transmission
capability.
The bit rate (High Bit Rate/HD-SDI) of optical
transmission between the camera and the camera control
unit is automatically switched, depending on connected
devices.
The HKCU2005 3G Single Link Interface Unit is a
function enhancement unit for the HDCU1000 with an
HKCU-HB10 installed and the HDCU1500 with an
HKCU-HB15 installed.
When an HKCU2005 is installed, max. four 3G-SDI signal
outputs can be fed from the camera control unit.
If these products are installed incorrectly, personal injury
or damage to peripheral items may occur due to fire, shock,
or other accidental circumstances. To avoid such risks,
installation should be performed by trained service
technicians.
About the manuals
This operation manual introduces the outlines of systems
which can be established by installing the above-
mentioned products in a camera or camera control unit,
and it describes the functions added or changed by the
function enhancement.
For conventional functions and operations of the camera or
camera control unit, refer to the operation manual supplied
with the camera or camera control unit.
Camera Systems That Become
Available
The following camera systems become available with the
3G Fiber Transmission Units. (There are some restrictions,
depending on the model and combination of the products.
See the table “Additional Functions” in the next
paragraph.)
• Fiber transmission system of Dual Link
1)
or
Single Link
2)
format (signal transmission at “High Bit
Rate”)
• COAXIAL connection system of Single Link format
using two coaxial cables
• Dual-Camera system
• Sub-Camera system (Only HDCU1000 with an HKCU-
HB10 installed can be the main camera control unit.)
HDC1000R/1500R/1000/1500-series models with no 3G
Fiber Transmission Unit installed can be used in
combination.
For connections and settings, see “Connections and
Settings” (page 23).
1) Dual Link formats:
1080/59.94P, 1080/50P
2) Single Link formats:
1080/59.94I, 1080/29.97PsF, 1080/23.98PsF, 720/59.94P, 1080/50I,
1080/25PsF, 1080/24PsF, 720/50P
Notes
• Connection compatibility with HDC-900-series models is
lost by function enhancement.
• Do not install the 3G Fiber Transmission Units in any
cameras or camera control units other than the applicable
models.
Camera /
Camera Control Unit
3G Fiber Transmission
Unit
HDC1000R
HKC-HB10
HDC1000
HDC1500R
HKC-HB15HDC1400R
HDC1500
HDCU1000
1)
HKCU-HB10
HDCU1500 HKCU-HB15
Precaution
