63
Specifications
FBAS-Kabel mit Steckern, wie in dieser Anleitung
beschrieben, um die Grenzwerte der geltenden EMV-
Vorschriften zu erfüllen.
Related equipment
HDC1000/HDC1500 series HD Color Video Camera
HDC1000R/HDC1500R series HD Color Video Camera
RCP-700/900 series Remote Control Panel
RM-B750 Remote Control Unit
MSU-900 series Master Setup Unit
VCS-700 Video Selector
CNU-700 Camera Command Network Unit
HDS-X3400 Multi Bitrate Routing Switcher
Design and specifications are subject to change without
notice.
HKCU1001 (optional)
General
Power supply 2.5 W
Operating temperature
–10°C to +40°C (+14°F to +104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Dimensions (w/h/d)
EN-A board: Approx. 19 × 110 × 226 mm
(3/4 × 4 3/8 × 8 7/8 inches)
VDA-A board: Approx. 19 × 98 ×
159 mm (3/4 × 3 7/8 × 6 1/4 inches)
Mass EN-A board: Approx. 0.22 kg (7.8 oz)
VDA-A board: Approx. 0.10 kg (3.5 oz)
Output connectors
VDA-A board
VBS BNC-type (2), 1.0 Vp-p, 75 ohms, VBS
PIX OUT BNC-type (1), VBS/R/G/B (VBS 1 Vp-p,
75 ohms)
WF OUT BNC-type (1), VBS/R/G/B/SEQ
(VBS 1 Vp-p, 75 ohms)
Supplied accessories
4-pin connector (1)
Design and specifications are subject to change without
notice.
HKCU1003 (optional)
General
Power supply 3.6 W
Operating temperature
–10°C to +40°C (+14°F to +104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Dimensions (w/h/d)
EN-B board: Approx. 19 × 110 × 226 mm
(3/4 × 4 3/8 × 8 7/8 inches)
VDA board (A/B/C): Approx. 19 × 98 ×
159 mm
(3/4 × 3 7/8 × 6 1/4 inches)
Mass EN-B board: Approx. 0.22 kg (7.8 oz)
VDA board (A/B/C): Approx. 0.10 kg
(3.5 oz)
Output connectors
VDA-A board
VBS BNC-type (2), 1.0 Vp-p, 75 ohms, VBS
PIX OUT BNC-type (1), VBS/R/G/B (VBS 1 Vp-p,
75 ohms)
WF OUT BNC-type (1), VBS/R/G/B/SEQ
(VBS 1 Vp-p, 75 ohms)
VDA-B board
FRAME REF IN
BNC-type (1)
HD: SMPTE-274M, tri-level sync,
0.6 Vp-p, 75 ohms
SD: Black burst (or 10F-BB),
0.286 Vp-p, 75 ohms (NTSC);
0.3 Vp-p, 75 ohms (PAL)
FRAME REF OUT
BNC-type (1), loop-through output or
frame sync pulse output
HD: SMPTE-274M, tri-level sync input,
0.6 Vp-p, 75 ohms
SD: Black burst input, 0.286 Vp-p,
75 ohms (NTSC); 0.3 Vp-p, 75 ohms
(PAL)
PIX OUT BNC-type (1), VBS/R/G/B (VBS 1 Vp-p,
75 ohms)
WF OUT BNC-type (1), VBS/R/G/B/SEQ
(VBS 1 Vp-p, 75 ohms)
VDA-C board
VBS BNC-type (1), 1.0 Vp-p, 75 ohms, VBS
R/R-Y, G/Y, B/B-Y
BNC-type (3)
• R/G/B video
R/G/B (100% white): 0.7 Vp-p,
75 ohms
