Je bekijkt pagina 61 van 71
61
<TEST OUT>
M11 (U13)
OUTPUT SD-SYNC, HD-SYNC, VF, VBS
VBS-OUT Displayed when OUTPUT is set to VBS.
CHARACTER ON, OFF
GAIN –99 to +99, 0
CHROMA –99 to +99, 0
SYNC-OUT Displayed when OUTPUT is set to SD-SYNC or
HD-SYNC.
V-PHASE –999 to +999, 0
H-PHASE –999 to +999, 0
DOWN CONVERTER Displayed when OUTPUT is set to VBS.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
<SDI OUT>
M12 (U14)
SDI-1 OUT OFF, MAIN/LINK-A
,
3G-SDI LEVEL-B,
HD PROMPTER,
3G-SDI LEVEL-A
SDI-2 OUT/IN OFF, MAIN/LINK-B OUT
, HD
TRUNK/RET IN
FRAME SYNCHRO is fixed ON when HD TRUNK/
RET IN is selected.
SDI-MONI OUT OFF, VF
, MAIN, RET, SD-SDI
CHARACTER ON, OFF
EMB AUDIO OFF, MIC, PGM
DOWN CONVERTER Displayed when SDI-MONI OUT is set to SD-SDI.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
<TRUNK>
M13
TRUNK ON
, OFF
INTERFACE 232c
, 422A
AUX REMOTE Display only
NETWORK TRUNK Display only
LINK
<GENLOCK>
M14
REFERENCE Synchronization status Display only
GENLOCK ENABLE
, DISABLE Not displayed when a BPU or CCU is connected.
STATUS
FORMAT
PHASE
V –1024 to +1023, 0
H –1700 to 1700, 0
<DATE>
M15
DATE/TIME 2000 to 2099/01 to 12/00 to 31
00 to 23 : 00 to 59
DATE FORMAT 1 Y/Mn/D, 2 Mn/D, 3 D/M/Y,
4 D/M, 5 M/D/Y
, 6 M/D
Y: Year
Mn: Month (numeric)
M: Month (English abbreviation)
D: Day
<BATTERY ALARM>
M16
BEFORE END 11.5
to 17.0 V
END 11.0
to 11.5 V
MAINTENANCE
Page name
Page No.
Item Settings Description
