Safety Information
5-018-115-19(1)
• NEVER place the LCD Monitor on cloth or other materials that
may be located between the LCD Monitor and supporting
furniture.
• NEVER place items that might tempt children to climb, such as
toys and remote controls, on the top of the LCD Monitor or
furniture on which the LCD Monitor is placed.
If your existing LCD Monitor is being retained and relocated, the
same considerations as above should be applied.
Ventilation
• Never cover the ventilation holes or insert anything into the
cabinet.
• Leave space around the LCD Monitor as shown below.
• It is strongly recommended that you use a Sony Wall-Mount
Bracket in order to provide adequate air circulation.
Installed on the wall
Installed with stand
(Models with Table-Top Stand only)
*1 1 cm for SU-WL8xx only. Refer Reference Guide to know
whether your LCD Monitor is compatible with this Wall-Mount
Bracket.
*2 FW-55BZ40H: 30 cm for SU-WL8xx
*3 FW-43BZ30J / 50BZ30J: 10 cm (Operating temperature: 38 °C
and lower) or 30 cm
• To ensure proper ventilation and prevent the collection of dirt
or dust:
Do not lay the LCD Monitor flat, install upside down,
backwards, or sideways.
Do not place the LCD Monitor on a shelf, rug, bed or in a
closet.
Do not cover the LCD Monitor with a cloth, such as curtains,
or items such as newspapers, etc.
Do not install the LCD Monitor as shown below.
* The ventilation condition is depending on your LCD Monitor
model. If this information is described in both Reference Guide
and this manual, please refer to the Reference Guide.
Mains lead
Handle the mains lead and socket as follows in order to avoid any
risk of fire, electric shock or damage and/or injuries:
• Use only mains leads supplied by Sony, not other suppliers.
• Insert the plug fully into the mains socket.
• Operate the LCD Monitor on a 220 V – 240 V AC supply only.
• When wiring cables, be sure to unplug the mains lead for your
safety and take care not to catch your feet on the cables.
• Disconnect the mains lead from the mains socket before
working on or moving the LCD Monitor.
• Keep the mains lead away from heat sources.
• Unplug the mains plug and clean it regularly. If the plug is
covered with dust and it picks up moisture, its insulation may
deteriorate, which could result in a fire.
Note
• Do not use the supplied mains lead on any other equipment.
• Do not pinch, bend, or twist the mains lead excessively. The
core conductors may be exposed or broken.
• Do not modify the mains lead.
• Do not put anything heavy on the mains lead.
• Do not pull on the mains lead itself when disconnecting the
mains lead.
• Do not connect too many appliances to the same mains socket.
• Do not use a poor fitting mains socket.
NOTE ON MAINS ADAPTOR (models with
supplied mains adaptor only)
Warning
To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
To prevent fire or shock hazard, do not place objects filled with
liquids, such as vases, on the apparatus. Do not install this
equipment in a confined space, such as a bookshelf or similar
unit.
• Please ensure that the mains socket is installed near the
equipment and shall be easily accessible.
• Be sure to use the supplied mains adaptor and mains lead.
Otherwise it may cause a malfunction.
• Connect the mains adaptor to an easily accessible mains
socket.
• Do not coil the mains lead around the
mains adaptor. The core wire may be cut
and/or it may cause a malfunction of the
media receiver.
• Do not touch the mains adaptor with wet
hands.
• If you notice an abnormality in the mains adaptor, disconnect it
from the mains socket immediately.
• The set is not disconnected from the mains source as long as it
is connected to the mains socket, even if the set itself has been
turned off.
• As the mains adaptor will become warm when it is used for a
long time, you may feel hot when touching it by hand.
Prohibited Usage
Do not install/use the LCD Monitor in locations, environments or
situations such as those listed below, or the LCD Monitor may
malfunction and cause a fire, electric shock, damage and/or
injuries.
Locations:
• Outdoors (in direct sunlight), at the seashore, on a ship or other
vessel, inside a vehicle, unstable locations, near water, rain,
moisture or smoke.
Environments:
• Places that are hot, humid, or excessively dusty; where insects
may enter; where it might be exposed to mechanical vibration,
near the source of naked flame, such as lighted candle, which is
placed on a LCD Monitor. The LCD Monitor shall not be exposed
to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the LCD Monitor.
Situations:
• Use when your hands are wet, with the cabinet removed, or
with attachments not recommended by the manufacturer.
Disconnect the LCD Monitor from mains socket during lightning
storms.
• Install the LCD Monitor so that it sticks
out into an open space. Injury or
damage from a person or object
bumping into the LCD Monitor may
result.
• Place the LCD Monitor in a humid or
dusty space, or in a room with oily
smoke or steam (near cooking tables
or humidifiers). Fire, electric shock, or
warping may result.
10 cm
*2*3
10 cm 2 cm
*1
Leave at least this space around the set.
10 cm
10 cm
Leave at least this space around the set.
10 cm
*3
10 cm
10 cm
6 cm
Air circulation is blocked.
Wall
Wall
Air
circulation
Do not block the air
circulation area.
(Models with Table-Top
Stand only)
