D:\SONY TV\SY23_B2B_UCF_RG_121\5049510121_01EN\5049510121_EN.fm master page: Left
FW-98BZ53L / 98BZ50L / 98BZ30L / 85BZ40L / 85BZ35L / 85BZ30L / 75BZ40L / 75BZ35L / 75BZ30L /
65BZ40L / 65BZ35L / 65BZ30L / 55BZ40L / 55BZ35L / 55BZ30L / 50BZ30L / 43BZ30L
5-049-510-12(1)
18
EN
• For security purposes, be sure to remove
all personal and account information
before discarding, selling or passing your
LCD Display to someone else by:
unlinking/unregistering, signing out of
and deactivating all network services as
well as factory reset the LCD Display.
The remote control does not function.
• Replace the batteries.
The restricted profile password has been
forgotten.
• Perform the force factory data reset.
Specifications
System
Panel system
LCD (Liquid Crystal Display) Panel,
LED Backlight
Speaker output (W)
FW-98BZ53L / 98BZ50L / 98BZ30L:
10 + 10 + 10 + 10
FW-85BZ40L / 85BZ35L / 85BZ30L /
75BZ40L / 75BZ35L / 75BZ30L / 65BZ40L /
65BZ35L / 65BZ30L / 55BZ40L / 55BZ35L /
55BZ30L / 50BZ30L / 43BZ30L: 10 + 10
Wireless technology
Protocol IEEE 802.11a/b/g/n/ac
Bluetooth® Version 4.2
Input/Output jacks
/ AV IN
Video/Audio input (mini jack)
S-CENTER SPEAKER IN (FW-98BZ53L /
98BZ50L / 98BZ30L only)
S-center speaker input (mini jack)
HDMI IN 1/2/3/4 (HDCP 2.3-compatible)
Video (FW-98BZ53L / 98BZ50L / 98BZ30L
only):
4096 × 2160p (60 Hz)*
1
*
2
, 4096 × 2160p
(24 Hz)*
1
, 3840 × 2160p (60 Hz)*
2
, 3840 ×
2160p (24, 30 Hz), 1080p (24, 30, 60,
120 Hz), 1080i (60 Hz), 720p (24, 30,
60 Hz), 480p, PC Formats
3840 × 2160p (120 Hz)*
2
*
3
Video
(FW-85BZ40L / 85BZ35L / 85BZ30L /
75BZ40L / 75BZ35L / 75BZ30L / 65BZ40L /
65BZ35L / 65BZ30L / 55BZ40L / 55BZ35L /
55BZ30L / 50BZ30L / 43BZ30L only):
4096 × 2160p (60 Hz)*
1
*
2
, 4096 × 2160p
(24 Hz)*
1
, 3840 × 2160p (60 Hz)*
2
, 3840 ×
2160p (24, 30 Hz), 1080p (24, 30, 60 Hz),
1080i (60 Hz), 720p (24, 30, 60 Hz),
480p, PC Formats
Audio:
In eARC (Enhanced Audio Return
Channel) mode
7.1 channel linear PCM: 32/44.1/48 kHz
16 bits, Dolby Digital, Dolby Digital
Plus, DTS, Dolby TrueHD, DTS-HD MA,
Dolby Atmos, DTS:X Master Audio
Except eARC mode
5.1 channel linear PCM: 32/44.1/48/
88.2/96/176.4/192 kHz 16/20/24 bits,
Dolby Audio, Dolby Atmos, DTS
eARC/ARC (Enhanced Audio Return
Channel/Audio Return Channel) (HDMI IN 3
only)*
4
In eARC mode
7.1 channel linear PCM: 32/44.1/48 kHz
16 bits, Dolby Digital, Dolby Digital Plus,
DTS, Dolby TrueHD, DTS-HD MA, Dolby
Atmos, DTS:X Master Audio
In ARC mode
Two channel linear PCM: 48 kHz 16 bits,
Dolby Audio, Dolby Atmos, DTS
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear
PCM: 48 kHz 16 bits, Dolby Audio, DTS)
HDMI 4 AUDIO IN
Analogue audio input (Stereo mini jack)
(Stereo mini jack)
Headphone
1, 2
USB port 1 supports High Speed USB
(USB 2.0)
USB port 2 supports Super Speed USB
(USB 3.2 Gen 1)
LAN
10BASE-T/100BASE-TX connector
(Depending on the operating
environment of the network, connection
speed may differ. The communication
rate and quality are not guaranteed.)
REMOTE
RS-232C mini jack
This jack is for receiving the external
control signal.
