1
Installing the LCD Display to the
Wall from Table-Top Stand*
1
*1
Only for limited region/country/model.
Remove the stand covers.
2
Remove the screws from the
rear of the LCD Display.
3
Attach the Wall-Mount Bracket
(not supplied) using the screws
(not supplied).
Wall-Mount Bracket
(not supplied)
4
Detaching the Table-Top Stand
from the LCD Display.
To detach the Table-Top Stand from the LCD
Display, remove the screws .
Note
• Be careful when lifting the LCD Display as the Table-
Top Stand is detached, the Table-Top Stand may
topple over and cause personal injury.
• Take care when removing the Table-Top Stand from
the LCD Display to prevent it from falling over and
damaging the surface that the LCD Display is sitting
on.
FW-85BZ40L / FW-85BZ35L / FW-85BZ30L /
FW-85EZ20L / FW-75BZ40L / FW-75BZ35L /
FW-75BZ30L / FW-75EZ20L / FW-65BZ40L /
FW-65BZ35L / FW-65BZ30L / FW-65EZ20L /
FW-55BZ40L / FW-55BZ35L / FW-55BZ30L /
FW-55EZ20L / FW-50BZ30L / FW-50EZ20L /
FW-43BZ30L / FW-43EZ20L
Installing the LCD Display to the
Wall from Carton*
1
*1
Only for limited region/country/model.
1
Remove the screws from the
rear of the LCD Display.
Screw (not supplied)
When using an electric screwdriver, set the torque
setting to approximately 1.5 N·m {15 kgf·cm}.
Do not lift the Wall-Mount Bracket (not supplied)
before the screws (two screws each for left/right)
are secured. This may distort the Wall-Mount
Bracket or the LCD Display cabinet.
10 (EN)
