3
Features
The DWM-30 is a digital wireless microphone for a
UHF synthesized wireless microphone system to
be used for broadcast or movie production
purposes. This transmitter is suitable for Electronic
News Gathering (ENG) and Electronic Field
Production (EFP). It is designed for use with a Sony
digital wireless receiver.
What is DWX?
DWX refers to Sony’s new digital wireless
microphone system. The DWX series reflects
Sony’s extensive expertise in professional
microphones and sound design. It represents a
successful blend of Sony know-how, wireless
technology renowned for stability, and digital
audio technology.
In addition to realizing the high
sound quality
possible with a digital system, the DWX series
supports multi-channel simultaneous operation,
encrypted transmission, and metadata
transmission for monitoring the status of multiple
transmitters. Using a main link and a separate
additional link, remote control of transmitters from
the receiver is also possible. With its many
advanced features, the system is ideal for the
workflow of professional applications.
What is WiDIF-HP?
WiDIF-HP (WiDIF: Wireless Digital Interface Format,
HP: High Profile) is a wireless digital audio interface
format developed by Sony.
It enables highly secure transmission with hi
gh
sound quality and low system latency, and
supports simultaneous multi-channel operation.
What is Cross Remote?
Cross Remote is a system that allows transmitters
to be monitored and controlled from a receiver and
the Wireless Studio control software installed on a
computer connected to the receiver.
For example, the settings of a transmitter worn
un
der clothing can be easily changed over the
wireless link.
Interchangeable microphone capsule
Coupled with a Sony microphone capsule unit (not
supplied), the DWM-30 can be used for vocal
performances, interviews, speeches, and a variety
of other applications. You can attach a microphone
capsule unit by simply screwing it onto the capsule
mounting area at the top of the DWM-30. The
microphone capsule unit has standard dimensions
with a diameter of 31.3 mm and a pitch of 1.0 mm
(1.25"/28 thread
pitch).
Simultaneous multi-channel operation
Simultaneous multi-channel operation is made
possible with the 375-kHz interval channel plan.
High sound quality and low latency
Low system latency of 0.7 ms (minimum) is
achieved when using CODEC MODE2.
Switch between five audio codec modes based on
your operational
needs.
For details, see “Audio codec mode setting (CODEC
MODE)” (page 15).
Encrypted transmissions
AES 256-bit encryption allows for highly secure
wireless transmissions.
Gain/attenuator settings for flexible audio
level
HIGH GAIN settings allow you to increase the gain
in three stages (6/12/18 dB) in situations where the
normal setting may
not be sufficiently sensitive.
The attenuator can be adjusted using 15 levels in
the range 0 dB to 42 dB.
RF transmission output switching
available
RF transmission output can be set to 2, 10, or
25 mW according to multi channel operation or
long-distance transmission priority.
For details, see “Setting the RF output power (RF
POWER)” (page 16).
User-set memory function
Various settings can be saved and activated on the
transmitter.
For further details, see “Settings storage function
(USER MEMORY)” (page 17).
Easy-to-grip design and light weight
An optimized mechanical structure achieves a grip
design that is easy to hold and is approximately
10% lighter than previous models.
Supports operation for long periods of
time and various battery types
The DWM-30 supports various battery types, such
as AA alkaline batteries, lithium batteries, and
NiMH batteries. It can be operated for
approximately 6 hours when powered by alkaline
batteries.
