Je bekijkt pagina 21 van 54
5 (E)
1 AC IN connector
Connects to an AC power source
through an optional AC power cord.
The AC IN connector can be rotated
up to 90° to obtain the most
convenient orientation of the AC
power cord.
Note
For details on rotating the AC IN
connector, consult Sony service
personnel.
2 POWER indicator
The indicator lights up when the
power is turned on. This indicator
does not light up, however, when the
BP-L60A/L90A Lithium Ion Battery
Pack is used as the back-up power
supply.
3 DC output connector for battery
charging (3-pin)
Supplies power for charging a BP-
L60A/L90A Lithium-Ion Battery Pack
attached through an optional BKW-
L601/2 Battery Adaptor.
The lower left pin is a sensor which
blocks the charging current when a
battery other than a Lithium-Ion
Battery has been mistakenly attached.
4 DC output connector (4-pin)
Supplies DC power through the
supplied DC power cord to portable
devices except camcorders. As to the
polarity of the connector pins, the
outside is plus and the inside is minus.
5 DC output connector (5-pin)
Supplies DC power to digital Betacam
camcorders such as the DVW-700/
700P/DNW-7/7P, portable editors and
field editors, connected directly to the
AC-DN1.
When the AC-DN1 is attached to a
Betacam SP camcorder, such as the
BVW-300/300P/BVW-400/400P,
through the optional BKW-L601 or
BKW-L601/2 Battery Adaptor, DC
power is supplied to the camcorder.
