Je bekijkt pagina 25 van 106
7 (E)
1 AC IN connector
Connects to an AC power source
through the supplied AC power cord.
2 DC output connector (XLR-type,
4-pin)
Supplies DC power through an
optional DC power cord to a portable
device except camcorder.
3 DC output connector for battery
charging (square-shaped, 5-pin)
Supplies power for charging a lithium-
ion battery pack.
The charging current is automatically
blocked when a battery pack other
than a lithium-ion battery pack has
been mistakenly attached.
4 Lock release lever
To remove the battery pack, pull the
battery pack upward while pushing the
lever.
5 AC power indicator
The indicator lights up when the AC-
DN10 is connected to an AC power
source. This indicator does not light
up, however, when the attached
lithium-ion battery pack is used as the
back-up power supply.
6 Charging indicator
Shows the charging status of the
attached battery pack.
For details on charging status, see
“About the charging indicator” on
page 13(E).
7 DC output connector (square-
shaped, 5-pin)
Supplies DC power to a camcorder,
portable editor or field editor,
connected directly to the AC-DN10.
