11
Mixers, Source Selectors & Switchers - RB- DSS10 2
Power Indicator
The LED on the front panel is used to indicate that power is present on the
unit. However, it also has a secondary role to indicate whether the selected
channel is routing the AES/EBU or S/PDIF input:
Red indicates AES/EBU input.
Amber indicates S/PDIF input.
The LED and remote tally flash, if the incoming audio signal is not present,
to indicate that the incoming digital signal is missing.
Illuminated Push Buttons
The front panel contains 10 illuminated push buttons, used for selecting a
digital source. The push button illuminates when the input is selected and
flashes when the selected input loses lock.
There is also a remote input to inhibit the front panel switches. When the
front panel inhibit is active, pressing the front panel switches has no effect
on the current channel selection.
Headphone Output
The output available on the front panel through a ¼” stereo jack socket, is
designed to drive 150 mW into 32Ωto 600Ω professional headphones.
Volume Control
The headphone output has its own volume control and has a maximum
output level of +12dBu.
Additional Modes
An option to set the unit in different modes of operation is available and
can be configured at anytime while the unit is powered.
There are currently three modes of operation: Alternate mode, Latched
mode and Protected Alternate mode: -
Alternate Mode
In this mode the channels are selected and deselected by a press of the
button, as described previously.
Latched Mode
In this mode the selected channel is active only while the button is pressed.
As soon as button is released the channel becomes inactive.
Protected Alternate Mode
Operates in a similar manner to the Alternate mode, but a channel cannot
be turned off unless switching to another input. In other words, there will
always be a channel routed to the output. NOTE: after setting this mode
there will be no channel selected.
Select & Confirm Mode
In this mode, input button 10 acts as a CONFIRM button for input selection
1 to 9. Once one of the inputs is pressed, this selection will then flash along
with button 10. You must press button 10 within 5 seconds to confirm the
selection or the original input selection times out. Only inputs 1 to 9 are
selectable and there is always an input channel routed in this mode. NOTE:
Initially, after setting this mode there will be no input selected.
Configuring the Additional Modes
While the unit is powered, hold down the input 10 button and press the
input 5 button five times. Once completed, the input 10 button will start
to flash and the first 3 input buttons will display the current operating
mode (as shown below). To change the mode, simply press the input 10
and the buttons will indicate the newly selected mode. Once the required
operating mode has been set the unit will restart within five seconds from
the last button press.
