3
Mixers, Source Selectors & Switchers - RB- SS10 1
Illuminated Push Buttons
The front panel contains 10 illuminated push buttons, used for selecting an
analogue source. The push button illuminates when the input is selected.
The status of pin 12 on the remote connector determines whether the unit
is in the selector mode, or the mix mode. When pin 12 is connected to 0V,
mix mode is enabled.
In selector mode, one push of a button will select the desired analogue
stereo source and pushing the button again will turn it off.
In mix mode, each button you press will select that source allowing
multiple sources to be mixed to a single output. Pressing the button again
will switch off a source.
There is also a remote input to inhibit the front panel switches. When the
front panel inhibit is active, pressing the front panel switches has no effect
on the current channel selection.
Front Panel Gain Controls
The input gain can be individually adjusted for left and right channels
through pre-set potentiometers which are accessible through the front
panel. The gain range of the input is -8dBu to +20dBu.
Headphone Output
The front panel headphone output is a ¼” stereo jack socket and is designed
to drive 150mW into 32Ω - 600Ω professional headphones.
Volume Control
The volume control is used to alter the headphone output. It can also be
used to alter the main XLR output levels by using a rear panel switch to
enable/disable the control.
Additional Modes
An option to set the unit in different modes of operation is available and
can be configured at anytime while the unit is powered.
There are currently three modes of operation: Alternate mode, Latched
mode and Protected Alternate mode: -
Alternate Mode
In this mode the channels are selected and deselected by a press of the
button, as described previously.
Latched Mode
In this mode the selected channel is active only while the button is pressed.
As soon as button is released the channel becomes inactive.
Protected Alternate Mode
Operates in a similar manner to the Alternate mode, but a channel cannot
be turned off unless switching to another input or while operating in mix-
mode and there is more than one channel active. In other words, there will
always be a channel routed to the output. NOTE: after setting this mode
there will be no channel selected.
Configuring the Additional Modes
While the unit is powered, hold down the input 10 button and press the
input 5 button five times. Once completed, the input 10 button will start
to flash and the first 3 input buttons will display the current operating
mode (as shown below). To change the mode, simply press the input 10
and the buttons will indicate the newly selected mode. Once the required
operating mode has been set the unit will restart within five seconds from
the last button press.
INPUT 1 button on = Alternate mode
INPUT 2 button on = Latched mode
INPUT 3 button on = Protected Alternate mode
