2 Configuration & Controls - DHY-04, DHY-04S, DHY-04T
12
Country Code Tone Disconnect Type Frequencies Disconnect Details DIPSwitch Set On Power Up
Spain 63 400Hz * Continuous 1+2+3+4+5+6
Sweden 64 400Hz * Continuous 7
Switzerland 65 400Hz * Continuous 1+7
Syria 66 400Hz * Continuous 2+7
Taiwan 67 400Hz * Continuous 1+2+7
TBR21 - ETSI 68 400Hz Continuous 1 OR 3+7
Thailand 69 400Hz * Continuous 1+3+7
Turkey 70 400Hz * Continuous 2+3+7
UAE 71 400Hz * Continuous 1+2+3+7
United Kingdom I 72 400Hz * Continuous 4+7
United Kingdom II 73 K-Break 1+4+7
United States I 74 400Hz * Continuous 2+4+7
United States II 75 Line Reversal 1+2+4+7
United States III 76 440Hz Continuous 3+4+7
Yemen 77 400Hz * Continuous 1+3+4+7
Avaya Media Gateway 111 Line Reverse 1+2+3+4+6+7
Nortel PABX 114 421Hz Cadence 250ms
On/250ms Off
2+5+6+7
Maple Audio 115 Line Reversal 1+2+5+6+7
ELMEG ICT-88 PABX 116 421Hz Cadence 200ms On
400ms Off
3+5+6+7
PHILIPS SOPHO PABX 117 425Hz Cadence 250ms On
250ms Off
1+3+5+6+7
Broadcast Bionics 118 N/A Always On
Always Connected
2+3+5+6+7
Broadcast Bionics
PhoneBox - Avaya
119 400Hz Cadence 375ms On
375ms Off
1+2+3+5+6+7
User Set 120 400Hz * Continuous Default values as ETSI 1+4+5+6+7
Table 2-1: Supported Disconnect Tone Details by Country.
(* - Provisional Disconnect Tone Setting Uses TBR21 default of 400Hz Continuous)
The Nortel, ELMEG and PHILIPS settings are for PABXs used in the
Netherlands which have non-standard disconnect tones.
The unit can be programmed with other settings, so please contact us if you
need the settings for a different country to be implemented. In this case, it
would be necessary to have a technical specification of the line conditions,
an audio recording or a specification of the disconnect tone parameters
(tone, line reversal or K-break).
