28
2 CM-CU21 Technical Specification
CM-CU21 Technical Specification
Microphone Input
Gain Range: +20dB to +86dB.
Maximum Input Level: -6dBu.
Equivalent Input Noise: 130dB Ref. 80dB gain with 150Ω termination.
Equivalent Input Noise: 128dB Ref. 50dB gain with 150Ω termination.
C.M.R.R.: >60dB.
Frequency Response: ±0.5dB 20Hz to 22kHz Ref 50dB gain @ 1kHz.
Electronically Balanced Line Input
Gain Range: -83dB to +10dB.
Maximum Input Level: +25dBu.
C.M.R.R.: >70dB.
Frequency Response: ±0.2dB 20Hz to 22kHz Ref 0dB @ 1kHz.
Transformer Balanced Monitor Inputs
Gain Range: -70dB to +7dB measured @ Headphone output.
Maximum Input Level: +25dBu.
C.M.R.R.: >60dB.
Frequency Response: ±0.5dB 20Hz to 22kHz Ref 0dB @ 1kHz.
Transformer Balanced Main Outputs
Maximum Output Level +24dBu.
(limiter off):
Frequency Response: ±0.5dB 20Hz to 22kHz Ref 0dB @ 1kHz.
Noise: -94dB Average weighting Ref +8dB Line input.
THD & N: <0.02% Ref. 1kHz @ +8dBu.
THD & N: <0.065% Ref. 1kHz @ +18dBu.
1% Distortion Point: +18dBu @ 24Hz.
Transformer Balanced Talkback Outputs
Maximum Output +8dBu.
Level Limited:
Frequency Response: ±0.5dB 20Hz to 22kHz Ref 0dB @ 1kHz.
Noise: -94dB Average weighting Ref +8dB Line input.
THD & N: <0.02% Ref. 1kHz @ +8dBu.
Gain Adjustment: 0-12dB
Electronically Balanced Comm Outputs
Maximum Output
Level Limited: +25dBu.
Frequency Response: ±0.2dB 20Hz to 22kHz Ref 0dB @ 1kHz.
Noise: -98dB Average weighting Ref +8dB Line input.
THD & N: <0.002% Ref. 1kHz @ +8dBu.
Headphone Outputs
Gain Range: -66dB to +11dB.
Maximum Output Level: +19dBu.
Frequency Response: ±0.5dB 20Hz to 22kHz Ref 0dB @ 1kHz.
Noise: -85dB Average weighting Ref +8dB Line input.
THD & N: <0.005% Ref. 1kHz @ +8dBu.
Main Panel Operational Controls & Indicators
On-Air 1-3 Buttons: Illuminated buttons with latching action
Talkback A & B Illuminated buttons with selectable momentary
Buttons: and/or latching action
Headphone Monitor Input source level adjustment potentiometers
Controls: Headphone channel selection switches
Line Input Level: Guest line input mode level potentiometer
