AVN-PX8x4C Mix Engine Rack 2
Front Panel Controls
Status LEDs
On the left side of the panel, there are a number of status LEDs which are
used to provide a basic overview of various system parameters such as
power supply failure, network and sync/clock failures.
Each of these LEDs can be illuminated in different combinations of colours
and flashing or non-flashing states. The table below provides an overview of
what each LED state signifies.
Led Name State Description
AoIP Red No network connection on AoIP network port
Green AoIP network port connected.
Ethernet Red No network connection on control network port
Green Control network port connected.
Auth Off Auth LED not currently used.
Clock Red PTP master offset clock is greater than 10000ns.
Yellow PTP master offset is less than 10000ns but
greater than 1000ns.
Green PTP master offset is less than 1000ns. Or this
unit is the master clock.
Flash
Yellow
PTP in listening state – master clock negotiation
taking place.
PSU1/
PSU2
Red Power state error
Yellow Power state warning
Green Power state is OK
OLED Display
The OLED display allows the user to view system info such as the IP address,
serial number etc. It also allows the user to name the unit, check or change
the network settings, set brightness of the LEDs or contrast of the OLED,
and to change the mixer sources used for the selected Virtual Mixer. These
menus are selected by pressing the menu fast key (see below) or holding
down the centre button on the selector spinwheel for around half a second,
and they can be set to require a password before access is granted.
Menu fast keys
The are 4 menu fast keys are available to help jump to the corresponding
menu on the OLED display.
• “Menu” jumps to the Main menu.
• “Assign” jumps to the VM assign menu where the user can assign a VM
to a particular group of MPPRs.
• “Release” jumps to the release menu which allows the user to release a
particular group of MPPRs.
• “Grab“ jumps to the grab menu which allows user to grab a particular
group of MPPRs.
Power button
The Front Panel on/off button is configured to power up the unit from
Standby mode and can be enabled to provide a power off function. The
function will always default to power off disabled - the user would need to
enter the system menu to enable this function. When the power off
function is enabled, pressing and holding the power button for 2 seconds
will power down the unit.
Reset button
The recessed reset button at the bottom left corner of the front panel
triggers a hardware reset of the unit.
