4.6 Technical data
Core module ENTRAcode+ FD UP AP
Supply voltage 12 V AC / 8 - 24 V DC Battery 4 x AA 1.5 V
Max. current consumption (at 12 V
DC)
1.0 mA
Operating temperature range
- 25 °C ... 65 °C - 20 °C ... 55 °
IP protection class IP65 IP54
Radio commands 1 (Standard mode) / max 5 (Extended mode)
Radio receiver ENTRAcode+ RX
Supply voltage 12 V AC / 8 - 24 V DC
Max. current consumption 14 mA
Max. switching capacity 2.5 A AC / DC
Memory locations 112
Pulse duration
3 s (factory setting - can be changed via SOMlink)
Toggle optional
Timer optional (can be set via SOMlink)
IP code (installed) IP20
Operating temperature range
- 25 °C ... 65 °C
Door opener contact (potential-free) connectible
Door opening pulse (non-oating) 6 ... 24 V AC / DC connectible
Radio (core module and receiver)
Radio frequency SOMloq2 868,95 MHz (868,3 MHz, 922,5 MHz)*/ SOMloq Rollingcode 868,8 MHz
Encryption 128 bit AES
Number of possible commands
ENTRAcode+ 1-5 commands
Receiver, 1-channel
Radio range approx. 50 m
* Various radio frequencies can be supplied, depending on the country of destination
