1.2 Inverter Wire Box and Connection Points
Name Description
3. COM1
2. COM
4. COM2
1. DC Switch
10. PV Module Input
5. COM3
6. COM4
7. Smart Port
8. Backup
9. Grid
11. Battery Connection
12. DATA
This is the DC disconnect switch for the PV
Conduit for AC conductors to backup loads panel should be connected here
Conduit for AC conductors to the main service panel should be connected here
1. Introduction
User Manual
RS485 and CAN communication cables and parallel cables should go through these
Solis data logger gets connected here-only USB version of the loggers will work
RS485 and CAN communication cables and parallel cables should go through these
Communication cables for 14PIN terminal block should go through these
Communication cables for 14PIN terminal block should go through these
Conduit for PV conductors should be connected here
Conduit for Battery conductors should be connected here
02
Conduit for AC conductors to generator should be connected here
Extends the range of the inverter GPRS signal
(Not applicable to the USA, Australia, Europe)
AC Grid Port
AC Backup Port
PV Input
Battery Input
DC Switch
Data
Communication
Data Logging
Stick (Optional)
Smart Port
