43
The alarm page can display the current alarm and the historical alarm.
5.6.4 Alarm
<
<
Solis-3115022B100041
Solis-3115022B100041
Update: 15:28:4 6
Update: 15:28:4 6
Current Alarm
Historical Alarm
Alarm Message:
Alarm Code:
Alarm Grade:
Resolution Method:
HeartbeatLose
1065
EMGR
1.Check whether the
connection between the
parallel communication
wire is normal.
2. Restart the system and
confirm whether the fault
continues.
3. If it is not excluded,
please contact the
manufacturer’s customer
service.
Current Alarm
Historical Alarm
5. Commissioning
User Manual
Alarm Message:
Alarm Code:
Alarm Grade:
Resolution Method:
Alarm Time:
2023-04-01 16:27
HeartbeatLose
1065
EMGR
1.Check whether the
connection between the
parallel communication
wire is normal.
2. Restart the system and
confirm whether the fault
continues.
3. If it is not excluded,
please contact the
manufacturer’s customer
service.
The interface can display the current work mode, Self-Use/Feed in Priority/Off-Grid.
Mode Setting
5.6.5 Settings
Battery Setting
Battery Model: select the battery model to be connected.
Peak-shaving setting: If the switch is enable, the power of force charging will be
dynamically adjusted.
Few samples to be clear: (Forcecharge Limited Power Setting=4kW)
If the load=3kW,PV=0kW,P_forcecharge=P_Grid(4kW)-P_ Load(3kW)=1kW.
If the load=10kW,PV=0kW,P_forcecharge=0kW,P_Grid=P_Load=10kW.
ECO Function: If PV power is lower than 100W and SOC falls below overdischarge SOC,
the inverter will turn off the grid relays and IGBT switching. If forcecharge SOC is reached,
it will connect back to grid and charge battery back to overdischarge SOC, then turn off again.
Battery wake up: After Battery wake up command, the inverter powers the DC battery port
using Battery Wakeup Voltage and low AMP till BMS communication of battery will be restored
and within awaken time.
Over-discharge SOC: When the battery is discharged to the over-discharge soc, the battery
will nor discharge actively.(Due to the internal current, conduction, there is a small self-
consumption power, if not charged for a long time, the SOC will slowly continue to decline.)
