Connection Points
From the PV array to the DC+
and DC- terminals in the inverter
From the battery (+) and (-) terminals to
the inverter BAT+ and BAT- terminals
From the OCPD in the main service panel to
the AC-GRID L1, L2, L3 terminals
From the backup loads subpanel OCPD to
the inverter AC-BACKUP L1, L2, L3 terminals
From the main service panel ground bar to
the ground bar inside the inverter wire box
PV DC connection
to the inverter
Battery DC connection
to the inverter
Inverter AC connection
to the main service panel
Inverter AC connection
to the backup subpanel
PV Cables
Battery Cables
AC Grid Cables
AC Backup Cables
Ground Cables
From meter to terminal HM.
For more details, refer to figure
Installing the energy meter
From battery to terminal BMS.
For more details, refer to figure
Installing the battery
USB COM port at the bottom of the inverter
(For more details, please refer to the
Solis data logger product manual)
Communication
between inverter & CT
Communication between
the inverter & the battery
Monitoring of the system
on SolisCloud
CT cable
Battery
communication cable
Data Logger
(Optional)
Grounding conductors
for the system
Purpose
NOTE
Conductor dimensions and OCPD sizing to be determined in accordance
with the national electrical code (NEC) and local standards.
3.4 Inverter Wiring Overview
User Manual
3. Installation
13
