• A MIDI enabled Drum Machine connected to the MIDI output
• A computer connected to the USB 2.0, 'C' Type port using one of the provided cables
• A Pair of Headphones connected to HEADPHONES A & B
Selecting Your Input and Setting Levels
Dynamic & Passive Ribbon Microphones
Plug your microphone into INPUT 1 or INPUT 2 on the rear panel using an XLR cable.
1. On the front panel, make sure that Neither +48V or LINE are pressed down.
2. Whilst singing or playing your instrument that has been mic'd up, turn the GAIN control up until you consistently get 3
green lights on the meter.
This represents a healthy signal level. It's OK to light up the amber LED (-10) occasionally but make sure you don't hit the
top red LED. If you do, you'll need to turn the GAIN control down again to stop clipping. Engage the High Pass Filter
switch to remove unwanted subsonic rumble, if you need it.
3. Push the LEGACY 4K switch to add some extra analogue character to your input, if you need it.
