63

17.2. TCP/IP BACNET

PRO-REG controller is equipped with an integrated RJ45 port

for TCP/IP communication, as support for BACnet IP commu-

nication. It’s necessary to conﬁ gure the IP address on each

controller, and activate and address the BACnet IP using

ETOOL software (E tool© is delivered as a self-installing pro-

gram and can be downloaded from

http://www.regincontrols.com/Root/Documentations/

42_105786/CorrigoEVentilation%203.4-1-24.zip)

It is necessary to indicate the names, IP ﬁ xed directions, sub-

net masks and default gateway of each unit connected to the same network.

18. REPLACEMENT OF THE BATTERY FROM THE CORRIGO PROGRAMMABLE

LOGIC CONTROLLER

When the “battery low” alarm appears and the red indicator light is lit, it means that the

backup battery to save the memory and the real time clock is too low.

The procedure to change the battery is described below.

A capacitor allows backing up the memory and running the clock for approximately 10

minutes after the power is switched off.

TCP/IP

45 U I 4

44 U I 3

43 A g n d

42 U I 2

41 U I 1

40 A g n d

35 A I4

34 A I3

33 A g n d
