5. TECHNICAL CHARACTERISTICS

VENTILATION SECTION

The UBTS-2 model incorporates a fan, while the UTBS-3,5 and 8 models have two. Each

model has associated a certain size of fan and motor.

The integrated controller, makes it possible to adapt the working point to the needs of

each installation, obtaining a high efﬁ ciency at the required working point.

4. UNIT LABELING

• The unit comes with a variety of labels that must not be removed. Herewith sample la-

bels and meaning:

ICON / LABEL MEANING

Signs on fan access door, indicates that the unit

must be disconnected, followed by a waiting

period, since there are moving parts that

constitute danger in case of access.

Indicates the airﬂ ow direction through the unit.

In case of units equipped with cold water coil,

it shows the water inlet and outlet.

In case of units equipped with hot water coil,

it shows the water inlet and outlet.

UTBS-5 M C4 0,75KW L L PRO-REG

5160172000 00AB0000

2 x 0,75 kW

2 x 1,75 kW

x kW

230 V

50 Hz

Hz

V

1018

Unit identiﬁ cation plate, which indicates:

- Model

- Code

- Serial number

- Date of manufacture

- Output power of installed motors (Kw)

- Maximum absorbed current of motor (A)

- Power of installed electric heater

- Electrical supply
