-.5. ASSEMBLING THE MODULES

Exist different accessories that can be supplied with UTBS module:

Before switch on the unit, verify that the duct system is free of obstacles to prevent or

modify the air circulation.

Model Flexible connection Sound

attenuator

Antivibrations support Visor Damper module Actuator

24V

UTBS-2 JF-UTBS 650x250 SIL-2 750 AM. DE MUELLE TM-50 VF UTBS-2 ID KIT COMP. UTBS-2

LF 24 S

UTBS-3 JF-UTBS 1000x300 SIL-3 750 AM. DE MUELLE TM-50 VF UTBS-3 ID KIT COMP. UTBS-3

UTBS-5 JF-UTBS 1400x300 SIL-5 750 AM. DE MUELLE TM-75 VF UTBS-5 ID KIT COMP. UTBS-5

UTBS-8 JF-UTBS 1800x400 SIL-8 750 AM. DE MUELLE TM-100 VF UTBS-8 ID KIT COMP. UTBS-8

*kd_ji

Antivibrator supports

Flexible

connection

Sound

attenuator

UTBS module

Actuator

Visor

Damper module

MOUNTING POSITION

Ant

i

v

i

brator su

pp

o

r

Flex

ible

nnect

i

o

n

S

oun

d

att

enua

t

o

r

UTB

S

modul

e

At t
