31/36 NT-51907601-ILHB-ILHT-ECOWATT-AN-170711
Pour information : Le débit est proportionnel à la vitesse de rotation.
Ｑ
v
= K x
√2,5 x set point
Size of ILHB/T-ECOWATT Coeff . K
500 250
630 428
710 473
5.10 ILHB/T-ECOWATT 3-phases - COP constant pressure control
During operation at constant pressure, the controller regulates the speed of the roof fan to obtain the set
pressure. If the display is present on the roof fan, it will show you the pressure in Pa. The pressure set
point can be adjusted by the potentiometer in the controller, by a CVF/REB-ECOWATT ON/OFF + varia-
tion remote control, by an external 0-10V output or by Modbus BMS.
5.10.1 Wiring
COP type factory assembly and wiring, with or without display. Connection of the power supply to the
INTZ switch to be done by the customer.
INTZ 15 A
1
2
3
456
7
8
9
10
11
12
13
14
15
16
17
18
19
M
Green/Yellow
U
V
W
+24V
Fire
+24V
Start/Stop
Green
Shunt
Shunt
Thermo switch
N/F
Speed-Output
GND
+24V
GND
An2
+10V
GND
An1
NO
COM
NC
Relay fault
PE
L1
L2
Controller
Black
Green/Yellow
Brown
A
B
PE
U
V
W
Black
Blue
Red
P
L2
L1
INTZ 15A
400V power supply
2
4
3
15
12
3
4
SW1
1
2
3
O
O
On
TDPD Display
Only on TED with display types
L3
Grey
Grey
6
L3
Brown
SPRD
pressure
sensor
Only on TED COP types
without display
Yellow
Black
Red
TDPD Display
only on ILHB/T
with display types
