14
3 Production Information
3.5 Specification
3.5.1 T-BAT-SYS-HV-S25
■
Configuration List
No. Model BMS
Battery
Module
Nominal
Energy
(kWh)
Operating
Voltage
(Vdc)
1 T-BAT HS5.0 TBMS-MCS0800 × 1 TP-HS25 × 2 5.12 90-116
2 T-BAT HS7.5 TBMS-MCS0800 × 1 TP-HS25 × 3 7.68 135-174
3 T-BAT HS10.0 TBMS-MCS0800 × 1 TP-HS25 × 4 10.24 180-232
4 T-BAT HS12.5 TBMS-MCS0800 × 1 TP-HS25 × 5 12.8 225-290
5 T-BAT HS15.0 TBMS-MCS0800 × 1 TP-HS25 × 6 15.36 280-349
6 T-BAT HS17.5 TBMS-MCS0800 × 1 TP-HS25 × 7 17.92 315-406
7 T-BAT HS20.0 TBMS-MCS0800 × 1 TP-HS25 × 8 20.48 360-465
8 T-BAT HS22.5 TBMS-MCS0800 × 1 TP-HS25 × 9 23.04 405-522
9 T-BAT HS25.0 TBMS-MCS0800 × 1 TP-HS25 × 10 25.6 450-580
10 T-BAT HS27.5 TBMS-MCS0800 × 1 TP-HS25 × 11 28.16 495-636
11 T-BAT HS30.0 TBMS-MCS0800 × 1 TP-HS25 × 12 30.72 540-695
12 T-BAT HS32.5 TBMS-MCS0800 × 1 TP-HS25 × 13 33.28 585-750
■
Performance
Module T-BAT HS5.0 T-BAT HS7.5 T-BAT HS10.0 T-BAT HS12.5 T-BAT HS15.0 T-BAT HS17.5
Nominal Voltage (Vdc) 102.4 153.6 204.8 256 307.2 358.4
Operating Voltage (Vdc) 90-116 135-174 180-232 225-290 270-349 315-406
Nominal Capacity (Ah) 50 50 50 50 50 50
Nominal Energy (kWh) 5.12 7.68 10.24 12.8 15.36 17.92
Usable Energy 90% DOD
(kWh)
4.6 6.9 9.2 11.5 13.8 16.1
Max. Charge/Discharge
Current (A)
45 45 45 45 45 45
Recommend Charge/
Discharge Current (A)
45 45 45 45 45 45
Standard Power (kW) 3.1 4.6 6.1 7.7 9.2 10.8
Max. Power (kW) 4.608 6.912 9.216 11.52 13.824 16.128
Short-circuit Current (A) 1900 1900 1900 1900 1900 1900
Battery Round-trip
Efficiency (0.2 C, 25°C)
95%
Expected Lifetime (25°C) 10 years
Cycle Life 90% DOD (25°C) 6000 cycles
Charge Temperature -30°C ~ 53°C (on heating function); 0°C ~ 53°C (off heating function)
Discharge Temperature -30°C ~ 53°C (on heating function); -20°C ~ 53°C (off heating function)
Storage Temperature
-20°C ~ 53°C (3 months)
10°C ~ 40°C (1 year)
Ingress Protection IP65
Protection Class I
Continued on the next page
