29
5 Equipment Installation
Step 8. Place BMS, and tighten M4x14 Phillips-head screws (× 2) on both sides
(Torque: 0.9 to 1.1 N·m)
Torque: 0.9-1.1 N·m
1 2
Installation steps with Series Box
In case of more than 10 sets of battery module (including 10), a Series Box needs
to be installed to connect two groups in series, and an accessories kit for Series
Box will not deliver for free.
The installation procedure for these two groups is the same as that for one
group. For details, please refer to the Step 1 to 8.
400 to
800 mm
An assembled bracket is
also required to installed
for this group.
BMS
Series Box
*Note:
The rule for the sequence of battery modules in the whole system is as follows:
In the case of one group, the battery module closest to the BMS is numbered the
first battery module, followed by the second battery module, the third battery
module, according to the top-down principle. If another group exists, the battery
module closest to the “Series Box” can be continued numbering based on the
group with the BMS.
