33
6 Wiring
6.3 Cable Connection
Before wiring, please:
Step 1. Remove the screws on both covers of the BMS,
Step 2. Press the cover;
1
2
*Note: Remove the silicone sleeves from the ports of BMS and Series Box (if any).
6.3.1 Wiring without Series Box
*Note: Please remove the labels attached to both cover plates before conducting
wiring.
Left side of BMS
Short power cable: Connect “B+“ and “B-“
HEAT
COM
HEAT
COM
Short power cable
Lock
button
There are two terminals
at both ends
