25
español english français portuguese deutsch italiano
Installation
1.. Select a level surface that provide enough open space for the intake and/or outlet vent
A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12 inches (30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
2. Plug your oven into a standard househol outlet. Be sure the voltage and the frequency is the
same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If
installed near or over a heat source, the oven could be damaged and the warranty would
be void.
OPERATION INSTRUCTION
This microwave oven uses modern electronic control to adjust cooking parameters
to meet your needs better for cooking.
1.Clock Setting
When the microwave oven is electried, the oven will display “0:00”, buzzer will ring once.
1))
Press “CLOCK/KITCHEN TIMER” once, the hour figure flash;
2))
Rotate
“ ”
to adjust the hour igures, the input time should be within 0--23.
3))
Press “CLOCK/KITCHEN TIMER”, the minute figures will flash.
4))
Rotate
“ ”
to adjust the minute igures, the input time should be within 0--59.
5) Press “CLOCK/KITCHEN TIMER” to nish clock setting. “:” will ash, the “ ”indicator will
go out.The clock setting has been nished.
Note: 1) If the clock is not set, it would not function when powered.
2))
During the process of clock setting, if you press “STOP “, the oven will go back to the
previous status automatically.
1.Microwave Cooking
1))
Press the “MICROWAVE” key once, and “P100” will display.
2))
Press “MICROWAVE” for times or rotate
“ ”
to select the microwave power from 100% to
10%. “P100”, “P80”, “P50”, “P30”, “P10” will display in order.
3))
Press “START/+30SEC./CONFIRM” to con irm.
4)
) Rotate
“ ”
to adjust the cooking time. (The time setting should be 0:05- 95:00.)
5)) Press “START/+30SEC./CONFIRM” to start cooking.
