ASSEMBLY INSTRUCTIONS
The heater is packaged with the feet
unattached. You must attach them before
operating the heater.
WARNING: Do not operate without feet
attached. Do operate the heater only
in upright position (feet on the bottom,
controls on the top), any other position
could create a hazardous situation.
1. Place the radiator body upside-down on a
scratch-free location, make sure it is stable
and will not fall.
2. Screw off the wing nuts from the U-shaped
bolt provided, attach the U-shaped bolt to the
(near the front cover).
3. To attach the castor mounting plate to the
radiator body, you should insert the threaded
ends of the U bolt in the holes on the castor
mounting plate.
4. Screw the wing nuts back to the U bolt and
fasten the wing nut properly.
Note: do not over tighten, which may cause
5. Repeat 2, 3 and 4 on the rear of radiator for
mounting of the rear castors.
Note: the rear castors must be mounted
INSTRUCTIONS FOR USE
1. Before using the heater, make sure that it is on
it is placed on an incline or decline.
2. Set all the controls to OFF position and
insert the plug into a socket-outlet with well
3. Rotate the thermostat knob clockwise to MAX
position and switch the heater to low, medium
and high
4. When your room reaches the desired
temperature, now slowly rotate the thermostat
knob counter clockwise until the pilot light
goes out. The thermostat can now be left at
this setting. As soon as the room temperature
has dropped below the set temperature, the
unit will switch it self on automatically until
the set temperature has been reached again.
In this way the room temperature remains
constant with the most economical use of
electricity.
5. If you want to change the room temperature
setting, rotate the thermostat knob clockwise
to raise the temperature, or counter clockwise
to lower it.
6. This heater includes an overheat protection
system that shuts off the heater when parts of
the heater are getting excessively hot.
7. To completely shut the heater off, turn all the
controls to OFF, and remove plug from the
socket-outlet.
14 español english français portuguese italiano deutsch
HOW TO USE THE HUMIDIFIER
If you want to use the humidifier, press the
"on / off" switch -G on the side panel
1. Pull out the humidifier
2. Take out the atomization nozzle
3. Fill purified water into the container
4. Insert the atomization nozzle into the
container.
5. Insert the humidifier into the front hole
6. Press the on/off switch, let the
humidifier start working.
