12
ENGLISH
2. Screw off the wing nuts from the U-shaped bolt provided, attach the U-shaped bolt to the U facing
ange between rst and second ns. (Near the front cover).
3. To attach the castor mounting plate to the radiator body, you should insert the threaded ends of the
U bolt in the holes on the castor mounting plate.
4. Screw the wing nuts back to the U bolt and fasten the wing nut properly.
Note: do not over tighten, which may cause the damage to radiator ange.
5. Repeat 2, 3 and 4 on the rear of radiator for mounting of the rear castors.
Note: the rear castors must be mounted between the last 2 ns.
Remark: Only for model SS-18455, t the front wheels assembly at the bottom of front panel by two
screws (see Fig 5), the other wheels assembly same as point 2, 3 and 4.
5. INSTRUCTIONS FOR USE
1. Before using the heater, make sure that it is on it is placed on a at and stable surface, damage
may occur on an incline or declined surface.
2. Set all the controls to OFF position and insert the plug into a socket-outlet with well grounded. make
sure that plug its rmly
3. Rotate the thermostat knob clockwise to MAX position and switch the heater to low, medium and
high
4. When your room reaches the desired temperature, now slowly rotate the thermostat knob counter
clockwise until the pilot light goes out. The thermostat can now be left at this setting. As soon
as the room temperature has dropped below the set temperature, the unit will switch it self on
automatically until the set temperature has been reached again. In this way the room temperature
remains constant with the most economical use of electricity.
5. If you want to change the room temperature setting, rotate the thermostat knob clockwise to raise
the temperature, or counter clockwise to lower it.
6. This heater includes an overheat protection system that shuts off the heater when parts of the
heater are getting excessively hot.
7. To completely shut the heater off, turn all the controls to OFF, and remove plug from the socket
outlet.
Tip-over protection
This heater is protected with a safety switch that turns off the appliance automatically when the heater
falls over, or is at an excessive angle from the horizontal. This helps prevent accidents, and the heater
will resume operation when it is put back upright.
Overheat protection
This heater is protected with overheat protection that switches off the appliance automatically in case
of severe overheating. In this case, unplug the appliance, wait about 30 minutes for it to cool and
remove any possible cause of overheating, e.g., something covering the heater. Check for damage to
the appliance, the cord and the plug. If there is no damage, plug the unit back in and switch it on as
described above. If the heater still does not turn on, please contact Customer Service for assistance.
MAINTENANCE
1. Always remove the plug from the socket-outlet and allow the radiator to cool down before clean the
heater.
2. Wipe radiator with a soft damp (not wet) cloth. WARNING:
Do not immerse the heater in water.
Do not use any cleaning chemicals such as detergents and abrasives.
Do not allow the interior to get wet as this could create a hazard.
3. To store away the heater, wind the cable round bobbin and store the heater in a clean dry place.
4. In case of malfunction or doubt, do not try to repair the radiator yourself, it may result in a re
Hazard or electric shock.
