5. Take the (right) cap/cover (4) from the bag and place it on the spot
from which the top hinge was removed. Remove and save the
cap/cover from the other side (5) to which the hinge will be
relocated.
6. Remove the cap (6) from the left side of the top door. Then, remove
the cap (7) from the right side of the top door. Place the cap (7) on
the left side of the top door and place the cap (6) on the right side
of the top door.
7. Undo the screw (8) and remove the door retainer (10) and the door
stop (9). Then, use a screw (8) to install the door retainer supplied
in the bag, and the door stop (9). Keep the door retainer (10) in
case you need it later.
8. Undo the screws from the middle hinge and remove it. Then,
remove the bottom door from the bottom hinge.
9. Lay the bottom door onto a smooth surface. Undo the screw (8)
and remove the door retainer (10) and the door stop (9). Then, use
a screw (8) to attach the door retainer supplied in the bag, and the
door stop (9). Keep the door retainer (10) in case you need it later.
10. Remove the middle hinge cap and replace it on the opposite side.
11. Tilt the appliance backwards and remove the adjustable foot (11).
12. Undo the three screws on the bottom hinge
(14) and remove it. Remove the extra foot
(12) from the bottom hinge pin (13).
Unscrew the pin (13) from the bottom hinge
and screw it onto the opposite side of the
hinge, complete with the extra foot (12).
16
