4X4 HDMI Matrix & WALL System 7
CONTROL USING THE FRONT PANEL
The front panel supports changing between several modes, Matrix, Wall, and the preset
saved onto Macro 1 and Macro 2.
To use Matrix Mode, select this mode and then select the desired Output and Input
respecvely. For example to set Input 1 on Output 3, the user must press Buon 5 -> Buon
3 (Output) -> Buon 1 (Input).
To use Wall Mode, select this mode and the select the desired Input.
To use the Macro buons, user must access the web page of QWALL-HD and set each
buon to a specic preset. Once the user saves the Macro buon from the web, QWALL-HD
will always change to the specic preset with the selected input unl the user updates
QWALL-HD to perform a new macro.
BUTTON DESCRIPTION
1 Input 1
2 Input 2
3 Input 3
4 Input 4
5 Matrix Mode
6 Wall Mode
7 Macro 1
8 Macro 2
There are a total of 8 buons used for the front panel of QWALL-HD.
