Ultra HD Video Wall Processor 6
REMOTE CONTROL
The EZW-UH4 supports IR control to manage inputs and video wall sengs. Using the included
remote, the instrucons are as follows:
SELECTING INDIVIDUAL
MONITOR
DESCRIPTION
1 -> Input 1 - 4 -> OK Display Input 1 on Output 1-4
2 -> Input 1 - 4 -> OK Display Input 2 on Output 1-4
SELECTING 1X2 WALL
1 -> SW/SP -> 1 Display Input 1 as a 1X2 wall using Output 1 + 2
1 -> SW/SP -> 2 Display Input 1 as a 1X2 wall using Output 3 + 4
2 -> SW/SP -> 1 Display Input 2 as a 1X2 wall using Output 1 + 2
2 -> SW/SP -> 2 Display Input 2 as a 1X2 wall using Output 3 + 4
SELECTING 2X1 WALL
1 -> SW/SP -> 3 Display Input 1 as a 2X1 wall using Output 1 + 3
1 -> SW/SP -> 4 Display Input 1 as a 2X1 wall using Output 2 + 4
2 -> SW/SP -> 3 Display Input 2 as a 2X1 wall using Output 1 + 3
2 -> SW/SP -> 4 Display Input 2 as a 2X1 wall using Output 2 + 4
SELECTING 2X2 WALL
1 -> SW/SP -> OK Display Input 1 as 2X2 wall using all Outputs
2 -> SW/SP -> OK Display Input 2 as 2X2 wall using all Outputs
CLEAR ALL STITCHING
Exit
Removes all stching and returns each Output to
Single Mode
