4. Observe the headlamp beam display on the wall. The beam displays at two
levels – higher on the right side and lower on the left side. When the beam is
properly adjusted, this measurement from the ground to the lower level beam
cutoff should be 21.5 in (54.6 cm)
5. To adjust a headlight beam, open the hood and turn the two upper headlamp
adjustment screws simultaneously and equally. Turning the adjustment
screws in tandem keeps the beam pointed straight, so as not to skew left or
right.
• Clockwise adjustment raises the beam
• Counter-clockwise adjustment lowers the beam
HEADLAMP BULB REPLACEMENT (CANADA)
When servicing a halogen lamp (bulb), avoid touching the lamp with bare
fingers. Oil from your skin leaves a residue, causing a hot spot that will shorten
the life of the lamp. If fingers do touch a lamp, clean it with denatured alcohol.
1. Pull the sealing boot away from the back of the bulbs and housing.
2. Press the looped end of the wire bulb retainer clip and swing the end toward
the center of the bulb to release it from the latch tab.
3. With the wire connector attached, pull the bulb out.
4. Disconnect the wire harness. Install the new bulb and secure the retainer.
5. Reinstall the sealing boot. Make sure it seals tightly around the bulb base
and lens to seal off from moisture.
HEADLAMP AIM ADJUSTMENT (CANADA)
1. Verify that headlamp aim inspection conditions are met. See page .
2. Position the vehicle on a level surface with the nose approximately 9.5 ft (2.9
m) from a wall
q
.
140
MAINTENANCE
