7
CAUTION
WARNING
The rangehood is quite heavy, so two people
will be needed for installation.
1. To install the appliance, adjust the position of the
adjustable side-springs using the supplied screws
(Fig. 5), according to the thickness of the board,
in which the appliance will be fixed.
2. Insert the rangehood into the cutout in the
cabinet until the stop click of the side-springs is
heard and the rangehood is supported.
3. Unscrew by 180° the horizontal screws as shown
in Fig. 5. During this action it is necessary to
support the hood with your hand (Fig. 5a).
4. Tighten the vertical screws to lift the height of the
hood upwards for a flush finish.
5. Repeat this operation for all four screws (Fig. 6).
6. If it is necessary, its possible to put other screws
along the front or rear of the product as shown in
Fig. 7. This is not absolutely necessary if the
cutout is the correct depth.
7. Insert the grease filter.
Before connecting any ducting to the motor,
make sure the non-return valves - which are on
the air outlet of the motor - can swing open.
External venting
• Connect the ducting to the outlet collar of the
rangehood and secure with a clamp.
• Run the ducting to your external vent/cowl,
making sure the appropriate ducting is used for
the entire run.
(Fig. 5)
Spring-loaded
clips
(Fig. 6)
(Fig. 5a)
(Fig. 7)
• NB: light is easier to remove from centre of
LED globe. Use a small, flathead screwdriver
(pictured), pallette knife or blunt butter knife.
