46

Under side

Côté de dessous

Reverso

Top side

Côté de dessus

Cara

ZIGZAG STITCHING

The top thread may appear on the bottom depending on the

thread, fabric, type of stitch and sewing speed, but the bobbin

thread must never appear on the top of the fabric.

If bobbin thread is pulling to the top or you are experiencing

puckering, slightly reduce the tension with the Thread Tension

Control.

SETTINGS :Presser foot - General Purpose Foot

:Thread tension control - AUTO

Dark grey box indicates the Auto/default value set

automatically when the pattern is selected.

For the Zigzag Pattern the stitch length is 2 mm and the

stitch width is 5 mm.

The light grey boxes indicate all the possible personal

preference options available to set manualy.

ADJUSTING STITCH WIDTH AND LENGTH

3/$&(0(172)3$77(516

The satin stitch increases from the center needle position;

making it possible to create center tapered stitch, as

illustrated.

SATIN STITCH

This is a closely spaced stitch for appliqué, bar-tacking, etc.

Slightly loosen the top thread tension and manually adjust the

stitch length between 0.5 and 2.0 for satin stitching.

Use a backing of stabilizer or interfacing to avoid puckering.

NOTE: When sewing a dense (closely spaced) Satin

Stitch, the Satin Stitch Foot MUST be used.

Center position

Position centrale

Aguja posicionada en el centro

STITCH LENGTH

LONGUEUR DU POINT

LARGO PUNTADA

STITCH WIDTH

LARGEUR DU POINT

ANCHO PUNTADA

mm 0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0

0

0.25

0.5

0.75

1.0

1.25

1.5

1.75

2.0

2.5

3.0
