WINDING THE BOBBIN

1. Place a spool of thread on the spool pin, and secure it with

the spool pin cap. Pull the thread out from the spool and

place it through thread guides as shown in illustration.

Be sure to pull thread securely into the bobbin winding

tension disk.

2. Put end of thread through the hole in bobbin as shown.

Push bobbin winder shaft to far left position, if it is not

already there.

3. Place bobbin onto shaft with end of thread coming from

top of bobbin. Push bobbin winder shaft to the right until it

clicks. Hold the end of thread.

4. Start machine and the bobbin starts to wind. Stop to trim

the thread tail, then step on the foot controller to resume

winding. Bobbin will automatically stop turning when

FRPSOHWHO\¿OOHG3XVKVKDIWWRWKHOHIWWRUHPRYHEREELQ

and cut thread.

2

3

4

1

Be sure to use only Class 15J bobbins.
