6.29
Back Latch
Components
77
Ultra High Speed Overedge and Safety Stitch Machine | Instruction Manual and Parts List
3 thread 4 thread 5 thread
1 205S16002 Nut 1 1 0
2 20528008 Washer 1 1 0
3 20512008 Connecting plate 1 1 0
4 205S30011 Screw 1 1 0
5 205S30012 Screw 1 1 0
6 205S16003 Nut 1 1 0
7 207S11005 Screw 2 0 0
8 20713044 Bracket 1 0 0
9 205S30013 Connecting screw 2 2 0
10 2051200900 Thread tension releasing wire assemb 1 0 0
11 205S16005 Nut 4 2 0
12 20527006 Spring 1 0 0
13 205S30009 Screw 1 0 0
14 206S11005 Screw 1 0 0
15 205S16004 Nut 1 0 0
16 20512005 Tension support 1 0 0
17 20512006 Thread tension releasing plate 1 0 0
18 205S30014 Screw 1 0 0
19 205S30007 Screw 1 1 0
20 20512002 Thread press plate 1 1 0
21 S02007 Screw 4 4 0
22 20512004 Knife supporter 1 1 0
23 205S30008 Screw 1 1 0
24 20512003 Pressing block 1 1 0
25 20519001 Small knife support 1 1 0
26 20527003 Spring 1 1 0
27 301S16007 Thread tension nut 1 1 0
28 20519002 Knife 1 1 0
29 XXXXXXXX Needle plate 1 0 0
30 XXXXXXXX Needle plate 0 1 0
31 20709021 Needle plate supporter (front) 1 1 0
32 XXXXXXXX Presser foot finger 1 0 0
33 XXXXXXXX Presser foot finger 0 1 0
34 XXXXXXXX Feed dog assembly 1 0 0
35 XXXXXXXX Feed dog assembly 0 1 0
36 2071206500 Cloth plate 1 1 0
37 20112060 Thread guide plate 0 1 0
38 20112061 Thread tension plate 0 1 0
39 201S16003 Nut 0 1 0
40 20112062 Frong frame 0 1 0
41 20112063 Thread tension releasing lever 0 1 0
42 20101039 Connector 0 1 0
43 201S20014 Connector screw 0 1 0
44 201S14003 Screw 0 2 0
45 201S20013 Screw 0 1 0
46 20127021 Spring 0 1 0
47 201S20012 Screw 0 1 0
48 20112059 Sleeve 0 1 0
49 20112058 Bracket 0 1 0
50 20103029 Collar 0 1 0
51 201S14002 Screw 0 1 0
52 201S11016 Screw 0 2 0
No. Part No. Description
Qty
