Je bekijkt pagina 63 van 84
6.20
Lubrication
Components (1)
61
Ultra High Speed Overedge and Safety Stitch Machine | Instruction Manual and Parts List
3 thread 4 thread 5 thread
1 2072000100 Oli pump assembly 1 1 1
2 20725002 Worm wheel 1 1 1
3 207S15002 Screw 2 2 2
4 2071100900 Oil distributor assembly 1 1 1
5 20709014 Plug 2 2 2
6 207S30002 Screw 1 1 1
7 206S30009 Joint screw 1 1 1
8 20122033 Washer 10 10 10
9 207S13008 Screw 2 2 2
10 20701025 Tank 1 1 1
11 207S11005 Screw 2 2 2
12 20136001 Oli filter 1 1 1
13 20712035 Cover 1 1 1
14 207S11007 Screw 3 3 3
15 001028 O ring 1 1 1
16 20636001 Joint 2 2 2
17 206S30009 Joint screw 2 2 2
18 20629002 Clamp 2 2 2
19 30121021 Tube 1 1 1
20 20636001 Joint 2 2 2
21 206S30009 Joint screw 2 2 2
22 20629002 Clamp 2 2 2
23 30121021 Tube 1 1 1
24 20521009 Joint 2 2 2
25 20712036 Oil guide 1 1 1
No. Part No. Description
