6.12
Upper Looper
Components
45
Ultra High Speed Overedge and Safety Stitch Machine | Instruction Manual and Parts List
3 thread 4 thread 5 thread
1 20705002 Connection assembly 1 1 1
2 207S11016 Screw 2 2 2
3 207S11005 Screw 2 2 2
4 20704003 Crank assembly 1 0 0
5 20704004 Crank assembly 0 1 1
6 S05018 Screw 1 1 1
7 20702004 Shaft 1 1 1
8 20628006 Washer 1 1 1
9 207S11004 Screw 1 1 1
10 20628005 Spring washer 1 1 1
11 20708006 Spacer 0 1 0
12 20622019 Oil Seal 1 1 1
13 20708007 Spacer 1 0 1
14 20705003 Lever assembly 1 1 1
15 207S12002 Screw 1 1 1
16 20726004 Pin assembly 1 1 1
17 20523005 Oil wick 1 1 1
18 207S14010 Screw 1 1 1
19 20704005 Upper looper holder assembly 1 1 1
20 20623005 Felt 1 1 1
21 207S11025 Screw 1 1 1
22 XXXXXXXX Upper looper 1 1 1
25 207S11026 Screw 2 2 2
26 20715007 Cover 1 1 1
27 207S17004 Screw 1 1 1
28 207S11027 Screw 1 1 1
29 20123021 Oil wick 1 1 1
30 20723005 Felt 1 1 1
31 20712017 Bracket 1 1 1
32 207S11020 Screw 1 1 1
No. Part No. Description
Qty
